APC SMART-UPS 5000VA 5U RM 19IN W/ SHUTDOWN SOFTWARE/USB/SER IN

Artikelnr:
SUA5000RMI5U
EAN:
0731304255321
  • Kapacitet 5kVA
  • Produkt Rackmonterad UPS
69 117:-
55 293,60 ex moms
I lager i butik (Väjern): Ej i lager
Webblager: ETA 2024-12-13
Beskrivning

APC Smart-UPS 5000VA 230V Rackmount/Tower

SUA5000RMI5U

APC Smart-UPS, 4000 Watts / 5000 VA,Input 230V / Output 230V, Rack Height 5 U

Includes: CD with software, Documentation CD, Installation guide, Rack mounting hardware, Rack Mounting support rails, Smart UPS signalling RS-232 cable, User Manual, Web/SNMP Management Card

Features

Adjustable voltage-transfer points
Audible alarms
Automatic self-test
Boost and Trim Automatic Voltage Regulation (AVR)
Cold-start capable
Disconnected battery notification
Hot-swappable batteries
LED status indicators
Network manageable
Plug-and-Play installation
Rack/Tower convertible
Resettable circuit breakers
Safety-agency approved
Serial Connectivity
SmartSlot
Temperature-compensated battery charging

Output

Output Power Capacity
4000 Watts / 5000 VA
Max Configurable Power
4000 Watts / 5000 VA
Nominal Output Voltage
230V
Output Voltage Note
Configurable for 220 : 230 or 240 nominal output voltage
Efficiency at Full Load
96.00%
Output Voltage Distortion
Less than 5% at full load
Output Frequency (sync to mains)
47 - 53 Hz for 50 Hz nominal
Crest Factor
3 : 1
Waveform Type
Sine wave
Output Connections
(8) IEC 320 C13
(2) IEC 320 C19
(6) IEC Jumpers

Input

Nominal Input Voltage
230V
Input Frequency
50/60 Hz +/- 3 Hz (auto sensing)
Input Connections
Hard Wire 3-wire
Input voltage range for main operations
160 - 286V
Input voltage adjustable range for mains operation
151 - 302V

Batteries & Runtime

Battery Type
VRLA
Typical recharge time
3 hour(s)
Replacement battery cartridge
RBC55
RBC™ Quantity
2
Typical Backup Time
at Half Load
26.7 minutes (2000 Watts)
Typical Backup Time
at Full Load
9.4 minutes (4000 Watts)
Runtime Chart
Smart-UPS

Communications & Management

Pre-Installed SmartSlot™ Cards
AP9617
Control panel
LED status display with On Line : On Battery : Replace Battery and Overload indicators
Audible Alarm
Audible and visible alarms : configurable delays

Surge Protection and Filtering

Surge energy rating
480 Joules
Filtering
Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449

Physical

Maximum Height
222.00 mm
Maximum Width
483.00 mm
Maximum depth
660.00 mm
Rack Height
5U
Net Weight
97.73 KG
Shipping Weight
106.82 KG
Shipping Height
635.00 mm
Shipping Width
610.00 mm
Shipping Depth
762.00 mm
Color
Black
Units per Pallet
3.00

Environmental

Operating Environment
0 - 40 °C
Operating Relative Humidity
0 - 95%
Operating Elevation
0-9000 meters
Storage Temperature
-15 - 45 °C
Storage Relative Humidity
0 - 95%
Storage Elevation
0-15000 meters
Audible noise at 1 meter from surface of unit
53 dBA
Online Thermal Dissipation
430.00 BTU/hr

Conformance

Regulatory Approvals
C-tick,CE,EN 50091-1,EN 50091-2,GOST,GS Mark,VDE
Standard Warranty
2 years repair or replace

**The time to recharge to 90% of full battery capacity following a discharge to shutdown using a load rated for 1/2 the full load rating of the UPS
